Dr. Brian Abelson DC.

Whiplash: Part 3 – Symptoms, Exams & WAD Categorization

Updated: Aug 22


Woman Holding Her Neck

Manifestations of Whiplash Injury


The symptoms stemming from a whiplash injury span various body regions and can display a delayed onset, taking weeks to manifest after the initial incident.

The most prevalent symptoms following a whiplash incident include:

  • Neck discomfort: The most frequently reported symptom.

  • Headaches: Reported in 50% to 75% of cases as the second most common symptom. These headaches typically originate at the base of the skull (occiput) and tend to spread toward the head's top and frontal regions. (44)

  • Jaw discomfort: Temporomandibular Dysfunction, or TMJ, is a common issue following a vehicular incident.

  • Facial discomfort: This could be direct or referred to as facial pain.

  • Shoulder discomfort: Often perceived as a rotator cuff injury.

  • Pain between the shoulder blades: Also known as inter-scapular pain.

  • Arm Discomfort: Arm discomfort could involve muscles, tendons, and ligaments or be due to nerve compression. It might also be referred spinal pain from an injured facet joint or spinal disc.


Dizziness Image

Further Symptoms of Whiplash

  • Paresthesia: These abnormal sensations in the neck, shoulders, upper back, and arms are common, appearing in 33% to 100% of whiplash patients.

  • Balance issues: Often associated with the upper cervical area.

  • Sleep disturbances: Between 39-89% of whiplash victims report disruptions in their sleep patterns.

  • Dizziness: Frequently connected to the upper cervical area, dizziness is prevalent in up to 70% of patients with chronic symptoms. Approximately 34% of whiplash patients suffer from benign paroxysmal positional vertigo (BPPV), potentially leading to genuine vertigo.

  • Fatigue: The level of fatigue can be extremely severe in some instances.

  • Lower back pain: This is a common occurrence in whiplash cases.

  • Concentration and memory: Concentration and memory issues could result from a concussion sustained during the accident.

  • Psychological changes: Depression and anxiety are common psychological alterations.

  • Tinnitus: Perceiving ringing, buzzing, whistling, or other noises in one or both ears.

  • Visual disturbances: For instance, sensitivity to light (related to adrenal stress).

  • Weakness: After a whiplash injury, 80% to 90% of patients report neck or upper extremities weakness.



Assessment Process After Motor Vehicle Injury

Conducting a comprehensive physical examination following any motor vehicle injury is crucial. Any delay could have severe implications, both for the injury resolution and potential legal compensation if litigation is necessary.


Orthopaedic Assessment

Cervical Examination Demonstration Video

Cervical Examination

This video provides a detailed walkthrough of the examination process, including inspection and observation, palpation techniques, assessment of active and passive ranges of motion, and an orthopaedic examination focusing on the cervical region.


Peripheral Vascular Examination Video

Key Elements of Peripheral Vascular

Examination A peripheral vascular examination is crucial in identifying indications of vascular-related disorders. Recognizing and treating Peripheral Vascular Disease (PVD) can help prevent cardiovascular and cerebrovascular health complications. This video highlights routine procedures we incorporate into our everyday clinical practice.



Neurological Assessment


Cranial Nerve Examination Video

Cranial Nerve Examination - 12 Cranial Nerves

The Cranial Nerve examination is one of the ways that we assess sensory and motor dysfunction. We commonly perform this examination on all new patients.



Upper Limb Neuro Exam

Upper Limb Neuro Exam Video

The upper limb neurological examination is part of the over all neurological examination process, and is used to assess the motor and sensory neurons which supply the upper limbs. This assessment helps to detect any impairment of the nervous system. It is used both as a screening and an investigative tool.


Vestibular Ocular Motor Screening Video

Effective Concussion Evaluation - VOMS

VOMS, or Vestibular Ocular Motor Screening, is a method specifically formulated to identify indicators of a concussion, whether from sports, impact tests, or general concussions. It investigates the coordination of balance, vision, and movement systems. VOMS examines five distinct domains of vestibular (balance) and ocular (vision) motor impairment.


HINTS Exam Demonstration Video

HINTS Exam

The HINTS Exam serves as a diagnostic tool to distinguish benign peripheral disorders from central nervous system conditions, such as strokes. HINTS is an acronym for Head Impulse-Nystagmus-Test of Skew. The 'Head Impulse' component involves testing the function of the vestibulo-ocular reflex. A normal result on this test (HIT) strongly suggests that the cause of Acute Vestibular Syndrome is situated within the central nervous system.


Dix HallPike Maneuver Demonstration Video

Dix HallPike Maneuver - Vertigo

BPPV (Benign Paroxysmal Positional Vertigo) is among the leading causes of vertigo, characterized by a sudden feeling of spinning or the internal sensation of the head spinning. While BPPV vertigo can cause significant discomfort, it seldom poses a serious threat unless it heightens the risk of falls. This video will walk you through the Dix Hallpike maneuver, a fundamental step in diagnosing vertigo (BPPV).



Cervical Xray

Role of Diagnostic Imaging in Whiplash Assessment


Diagnostic imaging plays a crucial role in assessing the severity of soft-tissue damage and ruling out potential fractures following a whiplash injury. Depending on the specifics of the case, a range of imaging techniques might be employed, including X-rays, CT scans, ultrasound, and MRI.


X-rays

X-rays are typically the first line of imaging used, as they can quickly and effectively identify fractures or dislocations. However, they are less effective for identifying soft tissue injuries.


CT Scans

CT scans provide a more detailed image than X-rays and can better visualize both bone and soft tissues. These are useful when fractures are suspected but not clearly visible on an X-ray. However, they expose the patient to more radiation.


Ultrasound

Ultrasound imaging, on the other hand, is a safe, non-invasive method that can be used to assess soft tissue injuries. It uses sound waves to produce pictures of the inside of the body and can show movement of the internal tissues and organs, and blood flowing through blood vessels.


MRI

MRI scans offer the most comprehensive view of the body's internal structures. They are particularly useful for visualizing soft tissue damage, including damage to the muscles, ligaments, and intervertebral discs. However, they are more expensive and time-consuming than other imaging techniques.


Please note that while diagnostic imaging is critical, it's important to understand that for Grade 1 and Grade 2 Whiplash Associated Disorders (WAD), CT scans and MRIs are typically not employed.


It's crucial to remember that any signs of fracture or dislocation warrant immediate referral to an emergency medical department for further evaluation and treatment."





Post MVA, Woman Holding Her Head

Classification and Rating of Whiplash Associated Disorders (WAD)

The classification of Whiplash Associated Disorders (WAD) is based on the criteria set forth by the Quebec Task Force. This rating system is utilized by insurance companies to ascertain the extent of coverage provided to an individual who has sustained an injury.


Here's a breakdown of the WAD grading system:


  • Grade 0: There are no complaints or physical signs related to the neck. Essentially, the individual does not report any neck pain, stiffness, or discomfort, and there are no observable physical signs of injury.

  • Grade 1: The individual complains of neck pain, stiffness, or tenderness, but there are no physical signs of injury. This means that while the individual might express discomfort or pain, a physical examination does not reveal any tangible signs of damage or trauma.

  • Grade 2: In addition to complaints of neck pain, there are also musculoskeletal signs present. These signs could include a decreased range of motion in the neck (which is a common symptom following a whiplash injury), as well as point tenderness. Point tenderness refers to a localized, sharp pain that occurs when a specific area is touched or pressure is applied.

  • Grade 3: At this level, the individual experiences neck discomfort and shows neurological signs. These neurological signs might include decreased or absent deep tendon reflexes, muscle weakness, and various sensory deficits, such as numbness or tingling in certain areas.

  • Grade 4: This is the most severe grade of WAD. It involves neck complaints and the presence of a fracture or dislocation. This means that the whiplash injury has led to significant structural damage in the neck, necessitating immediate and potentially intensive medical intervention.


The above classification is not just essential for insurance purposes but also guides the treatment approach and prognosis. Understanding the grade of WAD helps healthcare providers develop a tailored treatment plan to address the specific symptoms and injuries of the individual."




Final Thoughts Image

Conclusion


In conclusion, understanding the complexity and wide range of symptoms associated with whiplash injuries is crucial for effective diagnosis and treatment. From the immediate onset of neck pain to the delayed manifestation of psychological changes, the signs of whiplash are diverse and often interconnected. Moreover, various physical examination methods, from inspection to orthopaedic examination, are instrumental in assessing the severity of the injury.


We've also highlighted the essential role of diagnostic imaging in ruling out possible fractures and determining the extent of soft-tissue damage. Remember, Whiplash Associated Disorders are categorized into grades by the Quebec Task Force criterion, a classification system which helps determine the extent of insurance coverage for the injured party. In the following instalment, we will take a closer look at the conservative treatment approaches for managing these disorders. Stay tuned to learn more about addressing both soft-tissue and joint injuries resulting from whiplash.




DR. BRIAN ABELSON, DC. - The Author


Photo of Dr. Brian Abelson

With over 30 years of clinical experience and a track record of treating more than 25,000 patients, Dr. Abelson developed the Motion Specific Release (MSR) Treatment Systems to provide powerful and effective solutions for musculoskeletal issues.


As an internationally best-selling author, he is passionate about sharing knowledge and techniques that can benefit the broader healthcare community. A perpetual student, Dr. Abelson continually integrates cutting-edge methods into the MSR programs, with a strong emphasis on multidisciplinary and patient-centered care.


Beyond his professional life, Dr. Abelson is a dedicated husband and father of two. He and his wife share a deep love for international travel, immersing themselves in different cultures, music, and the joy of connecting with people around the world. An Ironman triathlete and marathon runner for over 30 years, he is also a committed environmentalist with a passion for human rights. His practice, Kinetic Health, is based in Calgary, Alberta, Canada.




Please Note: References for all five sections of this article can be found at the end of Part Five.
